leo学习系列之三——leo基础用法算子

leo学习系列之三——leo基础用法算子

1：改变布局

• 通过菜单命令:"Window/Toggle Split Direction" 设置

2：@file 标签（算子）：输出文件

• 位置：节点中
• @file节点必须包含@others（如果有子节点），否则会报错！删除子节点之后，子节点不存在父节点的@file文件中,但是子节点的@nosent会包含在父节点的@file中
• @file 下的@nosent不输出文件
• 在Leo 载入时，自动的将 @file 指示的文件，从外部文件更新入Leo 文件了,在Leo 中进行了编辑保存时，也会自动更新外部文件

3:@ignore

• 保存时，不改变外部文件。此项一般要去除。

4:@others @all

• 在使用 @file 标签后，

• 可以简单的使用 @others标签来包含当前结点以下的所有结点

• 象XSL 中的<xsl:for-each select="//."> 哈哈哈

• Copies the body text of all nodes  except section definition nodes in an @file tree to the corresponding external file.

对比：相同点@other不包括<<>>,@all 包括<<>>  ----在@nosent和@file中用法相同

These control how Leo places text when writing external files. They are two of the most important directives in Leo.

@all

Copies all descendant nodes to the external file. Use @all to place unrelated data in an external file.

The @all directive is valid only in the body of @file trees.

Within the range of an @all directive, Leo ignores the @others directive and section references, so Leo will not complain about orphan nodes.

@others

Writes the body text of all unnamed descendant into the external file, in outline order.

Whitespace appearing before @others directive adds to the indentation of all nodes added by the @others directive.

A single node may contain only one @others directive, but descendant nodes may have other @others directives.

5：自动导入

• Leo 的 /Import To @file 命令，支持对 C/C++/C#;Java;语言的自动分析文章化组织的导入

• 不过，自动生成的文本中可能有一些标签:
  • {{{@ignore

@language python }}}

• 是不属于 @file 管理范围的，

• 只要简单的注释掉，就可以成为标准的，可以自动同步外部文件的文本结点对象了

6：<<section>>

• 在 @root限定处理下，各子结点的引用，与包含处理是使用 <<章节>> 标记

7:Tangle & Untangle

• 这时，针对外部文件的同步，需要人工操作

  • 菜单命令:"/Tangle" - 混出

  • 菜单命令:"/Untangle" - 混入

  • 是一对相应的操作
    • Tangle 是将当前的编辑混出到外部文件中
    • Untangle 反之

8:@thin

大多数情况中 @thin 如同 @file 一样的工作. 实际上,你可以简单的将 @file 替换为 @thin 进行正常的 outline 操作.

这里是主要几点 @file 与 @thin 不同之处:

• Leo 不会在 .leo 文件的 @thin 节点树中保存信息
• 源自 @thin 的文件 (可以称作 "轻依赖"文件) 是从文件的outline 信息重建 @thin 树的. 具体的就是利用文本中 @+node 和 @-node 作为独特的标识节点
• . @all 指示符仅仅在 @thin 树中起作用. 此指示符与 @others 类似, 不过对其有些限制:(haoxiangbudui)
  • 它将倒出所有标记以內的节点到文件中，包括标记为 @ignore 和 @others 以下的树会当作普通的孤立节点倒出. (不妙的体验是,原先 @others 可以限定下属节点倒出文本时的缩进,而@all 粗暴的将所有下级节点当作同级的兄弟处理了!)

9:@root vs. @file 树

@file 树比 @root 树使用起来方便很多:

1. @file 树需要的指示符支持比 @root 树要少; 所有 @root 树中的章节都需要声明(而且不能重名,在同一文件中!), 而 @file 树常常包含很多非命名的章节节点. 在 @file 树中, @others 指示符 行为就象关联起所有非常命名的章节.
2. 工作在 @root 树中,用户必须明确调用 Tangle 和 Untangle 命令. 而 Leo 会自动混入/出 @file 树 , 保存时混出所有变动到 outline, 重新打开 .loe 文件时自动混入所有修改从 outline.

但是, @root 树比 @file 树要 柔韧很多:

1. 在 @file 树中, 章节必须是包含在子节点中的,而且引用点也是固定的.
2. 在 @root 树中一个被声明的章节, 并不限制其可以在哪里被引用. 此外,@unit 指示符命令甚至于扩展了章节的引用, 可以不限制在一个 @root 树中! 即,你可以在一个 @root 中命名一个章节, 而在另一个 @root 树中引用(可以看作 节点的 clone 操作,只是在引用处看不到全部内容,除非混出为文件)
3. 在 @root 中的章节声明,也不限制声明的地点.

@root 树与 @file 树不同之处在于:

1. 只有 @root 树可以包含章节定义行(不过 @file 中可以使用 "<< class declarations >>"类声明的专用章节)

2. 只有 @file 树可以包含 @others 指示符.
3. @c 指示符 需要章节名出现在 @root 的节点标题树中.
4. @c 指示符仅仅可以工作在 @file 树的体文本起始处.所谓 体文本是在 @root 中没有标记会被忽略,而在 @file 树是作为无命名的代码章节内容处理的节点正文文本.

The following table summarizes the various ways of creating external files.

Kind	Sentinels in external file?	Sections and @others expanded on write?	File data stored in .leo file?
@asis	no	no	yes
@auto	no	yes	no
@edit	no	no	no
@nosent	no	yes	yes
@shadow	Note 1	yes	no
@file @thin Note 2	yes	yes	no

Note 1: @shadow nodes create two files, a public file without sentinels and a private file with sentinels.

Note 2: @file and @thin nodes are synonyms.

• 经体验， 可以简单的使用 @nosent 替换 @root ,可以象 @file 一样的使用，却又没有Python格式的注释的结构信息
  • 而且，@others 章节声明也可以很好的混同使用

  • 只是不能象 @root 那样在正文中使用@root expfile.t2t 模式的声明，而必须在 outline 树节点中显要的指明

  • 如此就可以使用 Leo 方便的管理，编辑不支持 # 为注释的各种语言文件了

  • 嗯嗯 ？ 只是可惜的是这样一来，所有代码只能安全的存储在 .leo 文件中，生成的代码文件是干净了，但是团队开发时，就要反复同步 .leo 文件，否则，难以快速把握哪些文件受到修改了…………

10：@asis <path>

The @@ convention : Within @asis trees only, if a headline starts with @@, Leo writes everything in the headline following the @@ just before the corresponding body text.

解释;在@asis中，他的子节点以@@开头的话，那么@@后面的内容以及@@节点的内容都将被写进@asis文件中

@button

做测试用

• You can bind keys to the commands created by script buttons:

  @button my-button @key=Alt-8

在正文中写

g.es('Hello World!')

g.es('from fuwenchao!')

点击上面的my-button按钮，会在log pane中打印hello world，from fuwenchao 具体参加： .html#index-8 .html

@color

Enables syntax coloring until the next @nocolor directive.

@killcolor

Disables syntax coloring in a node, overriding all @color, @nocolor or @nocolor-node directives in the same node.

@nocolor

Disables syntax coloring until the next @nocolor directive.

@nocolor-node

Disables coloring for only the node containing it. The @nocolor-node directive overrides the @color and @nocolor directives within the same node.

@ and @doc

These directives start a doc part. @doc is a synonym for @. Doc parts continue until an @c directive or the end of the body text. For example:

@ This is a comment in a doc part.
Doc parts can span multiple lines.
The next line ends the doc part
@c

When writing external files, Leo writes doc parts as comments.

Leo does not recognize @ or @doc in @asis trees or when the @all or @delims directives are in effect.

@c and @code

Ends any doc part and starts a code part.

@code is a deprecated synonym for @c.

Leo does not recognize this directive in @asis trees or when the @all or @raw directives are

@encoding <encoding>

Specifies the Unicode encoding for an external file. For example:

@encoding iso-8859-1

When reading external files, the encoding given must match the encoding actually used in the external file or “byte hash” will result.

@first <text>

Places lines at the very start of an external file, before any Leo sentinels. @first lines must be the very first lines in an @<file> node. More then one @first lines may appear.

This creates two first lines, a shebang line and a Python encoding line:

@first #! /usr/bin/env python
@first # -*- coding: utf-8 -*-

Here is a perl example:

@first #!/bin/sh -- # perl, to stop looping
@first eval 'exec /usr/bin/perl -w -S $0 ${1+"$@"}'
@first     if 0;

@last <text>

Places lines at the very end of external files.

This directive must occur at the very end of top-level @<file> nodes. More than one @last directive may exist. For example:

@first <?php
...
@last ?>

Leo does not recognize @last directive in @asis trees.

@ignore 忽略节点

Tells Leo to ignore the subtree in which it appears.

In the body text of most top-level @<file> nodes, the @ignore directive causes Leo not to write the tree. However, Leo ignores @ignore directives in @asis trees.

Plugins and other parts of Leo sometimes @ignore for their own purposes. For example, Leo’s unit testing commands will ignore trees containing @ignore. In such cases, the @ignore directive may appear in the headline or body text.

   @edit <path>

   The @edit directive imports an external file into a single node.

When reading @edit nodes, Leo reads the entire file into the @edit node. Lines that look like sentinels will be read just as they are.

When writing @edit nodes, @edit nodes must not have children and section references and @others are not allowed.

@shadow <path>

The @shadow directive creates two external files, a public file without sentinels, and a private file containing sentinels.

When reading an @shadow node, Leo uses a brilliant algorithm devised by Bernhard Mulder that compares the public and private files, and then updates the outline based on changes to the public file. In this way, @shadow provides many of the benefits of @file trees without writing sentinels in the (public) external file.

Leo can do an initial import of @shadow trees by parsing the corresponding public file, exactly as is done for @auto nodes.

@pagewidth <n>

Sets the page width used to break doc parts into lines. <n> should be a positive integer. For example:

@pagewidth 100

The @pagewidth directive overrides the @int page_width setting.

@tabwidth <n>

Sets the width of tabs. Negative tab widths cause Leo to convert tabs to spaces.

@int page_width=60  节点上

@string target_language=rest 节点上

@language <language name>

Specifies the language in effect, including comment delimiters. If no @language directive is in effect, Leo uses the defaults specified by the @string target-language setting.

A node may contain at most one @language directive.

The valid language names are: actionscript, ada, autohotkey, batch, c, config, cpp, csharp, css, cweb, elisp, forth, fortran, fortran90, haskell, haxe, html, ini, java, javascript, kshell, latex, lua, noweb, pascal, perl, perlpod, php, plain, plsql, python, rapidq, rebol, rest, rst, ruby, shell, tcltk, tex, unknown, unknown_language, vim, vimoutline, xml, xslt.

Note: Shell files have comments that start with #.

Case is ignored in the language names. For example, the following are equivalent:

@language html
@language HTML

The @language directive also controls syntax coloring. For language x, the file leo/modes/x.py describes how to colorize the language. To see the languages presently supported, look in the leo/modes directory. There are over 100 such languages.

@lineending cr/lf/nl/crlf

Sets the line endings for external files. This directive overrides the @string output_newline setting.

The valid forms of the @lineending directive are:

@lineending nl	The default, Linux.
@lineending cr	Mac
@lineending crlf	Windows
@lineending lf	Same as ‘nl’, not recommended
@lineending platform	Same as platform value for output_newline setting.

@path <path>

Sets the path prefix for relative filenames for all @<file> tree.（@nosent也管用呀）

This directive may appear in headlines or body text, and may appear in top-level @<file> nodes.

The path is an absolute path if it begins with c: or /, otherwise the path is a relative paths.

Multiple @path directives may contribute to the path prefix. Absolute paths overrides any ancestor @path directives. Relative paths add to the path prefix.

If no @path directives are in effect, the default path prefix is the directory containing the .leo file.

Within @path and @<file> paths, {{exp}} gets evaluated with the following symbols known: c, g, p, os and sys. For example:

@file {{os.path.abspath(os.curdir)}}/abc.py

refers to the file abc.py in (absolute path of) the current directory.

@wrap

Enables line wrapping in Leo’s body pane.

Only the first @wrap or @nowrap directive in a node has any effect.

@wrap may appear in either headlines or body text.

@nowrap

Disables line wrapping the Leo’s body pane.

Only the first @wrap or @nowrap directive in a node has any effect.

@nowrap may appear in either headlines or body text.

@raw and @end_raw

@raw starts a section of “raw” text that ends  only with the @end_raw directive or the end of the body text containing the @raw directive. Within this range, Leo ignores all section references and directives, and Leo generates no additional leading whitespace.

更多请阅读：.html .html#index-1
